Hello, everyone. Today, let's introduce the problem of an 8 mm slide lamp belt. Is matrix slide lamp belt also called slide lamp belt? The following is a summary of this problem by Xiaobian. Let's have a look
Difference between four-line magic led strips and three line
The third line is to make the input and output on an IO port, and the fourth line is to separate the input and output
the color slide is more colorful, and beautiful, with better effect, and is easy to "attract money and customers", more concise, lower failure rate, convenient for customers to cut at will.
Smart lighting is used in bars, discos, gyms, KTVs, villas, hotel decorations, etc., and dream color led strips is used in gift boxes and other small things
What are the requirements for the wiring of slide lights with signal wires
1. Wiring method of LED light strip power connection LED light strip generally has a voltage of DC 12V, so it needs to use a switching power supply. The size of the power supply depends on the power and connection length of the LED light strip
2. Outdoor LED lamp belt installation, of course, the waterproof and firm installation of the lamp belt is the most important. The installation of LED light strips will mainly withstand the wind and rain. If 3M glue is used for fixing, the stickiness of 3M glue will be reduced and the LED light strip will fall off after a long time. Therefore, outdoor installation often adopts the method of fixing with a card slot. Where it needs to be cut and connected, the method is the same as that of indoor installation, but it needs to be additionally equipped with waterproof glue to consolidate the waterproof effect of the connection point. Then fix it with special fixing clips, which can be drilled with an electric hammer and fixed with plastic expansion tubes and screws
3. If a large power supply is used, the connection mode of the controller is. The LED running lamp belt and RGB full-color led strip light belt need to use a controller to achieve the change effect. When wiring, the full color led strip light belt is generally a common anode, that is, one of the lamp belts is +12v, and the others are all negative poles. RGB has three negative poles, as shown in the wiring above, and the control distance of each controller is different. Generally speaking, the control distance of the simple controller is 10-15m, The control distance of the remote controller is 15-20m, and the longest distance can be controlled to 30m. If the connection distance of LED led strips is long, and the controller cannot control such long led strips, it needs to use a power amplifier to tap
4. Generally speaking, the longest connection distance of 3528 series LED light strips is 20m, and the longest connection distance of 5050 series LED light strips is 15m. If the connection distance is exceeded, the LED light strip is easy to heat up, which will affect the service life of the LED light strip during use. Therefore, the installation must be carried out according to the manufacturer's requirements, and the LED light must not be overloaded
5. The wiring method of the monochrome 5050 patch LED light strip is to distinguish the positive and negative poles. Generally, we provide a welded power plug and plug it directly into the power supply of the light strip provided. If you don't want each LED light strip to be controlled by a power supply, you can buy a high-power switching power supply as the main power supply, and then connect all the LED light strips in parallel, which is uniformly powered by the main switching power supply. In this way, it can be controlled centrally, but it is inconvenient to realize the lighting effect and switch control of a single LED strip
What is the signal transmission of slide lights
The full color led strip light belt signal transmission is to use the current signal to directly connect the lamp belt to the power supply, and then the lamp belt can be lit
How to connect the slide lamp belt
first, turn off the electric valve switch, then install the buckle where the lamp belt is to be installed, and then press the lamp belt in the buckle, so that the lamp belt will not change at will. Connect the incoming wire on the lamp belt with the main wire, and finally turn on the electric valve
The above is Xiaobian's answer to the question about the 8 mm full color led strip light belt, which is also called a full-color led strip light belt. I hope it is helpful to you
