Hello, everyone. Today, let's introduce the effect of 10 slides. The following is a summary of this problem by Xiaobian. Let's have a look.
difference between four line magic light band and three line
The third line is to make the input and output on an IO port, and the fourth line is to separate the input and output
the color slide is more colorful, beautiful, better effect, easy to "attract money and customers", more concise, lower failure rate, convenient for customers to cut at will.
what should I pay attention to when installing the slide ribbon
1. To connect the controller, you need to use a special controller to connect the LED running lamp belt and RGB magic lamp belt to achieve the changing effect of the lamp. When wiring, the magic lamp belt is generally a common anode, that is, one of the lamp belts is plus 12V, and the others are negative RGB three negative poles
2. Moreover, the control area of each connected controller is also inconsistent. Generally speaking, the control distance of simple controller is generally about 12 meters, the control range of remote controller is generally about 20 meters, and even the area can reach more than 30 meters
3. Pay more attention to the distance between the LED lights when connecting the light belt. Generally speaking, the connection area of the LED light belt is 20 meters. If it exceeds this distance range, the LED light belt is very easy to heat up, and the service life of the LED light belt will be affected during use. Therefore, we must install it according to the manufacturer's requirements when installing it. We must avoid overload operation of the LED light belt to ensure the safety of use.
what are the requirements for the wiring of slide lights with signal wires
1. Wiring method of LED light strip power connection LED light strip generally has a voltage of DC 12V, so it needs to use switching power supply. The size of the power supply depends on the power and connection length of the LED light strip
2. Outdoor LED lamp belt installation, of course, the waterproof and firm installation of the lamp belt are the most important. The installation of LED light strip will mainly withstand the wind and rain. If 3M glue is used for fixing, the stickiness of 3M glue will be reduced and the LED light strip will fall off after a long time. Therefore, the outdoor installation often adopts the method of fixing with a card slot. Where it needs to be cut and connected, the method is the same as that of indoor installation, but it needs to be additionally equipped with waterproof glue to consolidate the waterproof effect of the connection point. Then fix it with special fixing clips, which can be drilled with an electric hammer and fixed with plastic expansion tubes and screws
3. If a large power supply is used, the connection mode of the controller. The LED running lamp belt and RGB magic lamp belt need to use a controller to achieve the change effect. When wiring, the magic lamp belt is generally a common anode, that is, one of the lamp belt is +12v, and the others are all negative poles. RGB three negative poles, as shown in the wiring above, and the control distance of each controller is different. Generally speaking, the control distance of the simple controller is 10-15m, The control distance of the remote controller is 15-20m, and the longest distance can be controlled to 30m. If the connection distance of LED light band is long, and the controller cannot control such a long light band, it needs to use a power amplifier to tap
4. Generally speaking, the longest connection distance of 3528 series LED light strips is 20m, and the longest connection distance of 5050 series LED light strips is 15m. If the connection distance is exceeded, the LED light strip is easy to heat up, which will affect the service life of the LED light strip during use. Therefore, the installation must be carried out according to the manufacturer's requirements, and the LED light must not be overloaded
5. The wiring method of the monochrome 5050 patch LED light strip is to distinguish the positive and negative poles. Generally, we provide a welded power plug and plug it directly into the power supply of the light strip provided. If you don't want each LED light strip to be controlled by a power supply, you can buy a high-power switching power supply as the main power supply, and then connect all the LED light strips in parallel, which is uniformly powered by the main switching power supply. In this way, it can be controlled centrally, but it is inconvenient to realize the lighting effect and switch control of a single LED strip
the difference between jazz Mack light band and magic light band
Smart lighting is used in bars, discos, gyms, KTVs, villas, hotel decorations, etc., and magic ribbon is used in gift boxes and other small things
what is the signal transmission of slide lights
The magic lamp belt signal transmission is to use the current signal to directly connect the lamp belt to the power supply, and then the lamp belt can be lit
The above is the Xiaobian's answer to the problem of the effect of 10 slides and related questions. I hope it is useful to you
